The 270 Series non-coded station will activate a positive alarm by pulling the alarm handle out and down. The station also provides a normally open alarm contact with a rating of 3 amps at 30VAC/60 Vdc. The finish is red enamel with aluminum markings. The 270 series Manual Stations can be semi-flush or surface mounted. The semi-flush style mounts to a recessed 4” (100mm) standard North-American electrical box with a single gang ½” (12mm) raised plaster cover. Surface mounting requires Catalogue number 27193-11 surface mount box.
Features:
• Single action models
• Pull lever for simple, positive operation
• Break glass operation
• Terminals or wire leads for field connections
• Surface or flush mounting
• Red finish
• Less than 5 lb pull force complies with ADA
• Solid, die-cast metal construction
• Operating temperature range: 32°F to 120°F (0°C to 49°C)
